| ▲ CONDENSERS |
▲ EVAPORATORS |
|
|
| |
|
| |
| 모델명 |
마력 |
S1 |
S2 |
S3 |
S4 |
| CB26 - 24H
|
2 |
E26(1'') |
E26(1'') |
H21(1 1/8'')
|
H21(1 1/8'')
|
| CB26 - 36H
|
3 |
E26(1'') |
E26(1'') |
H21(1 1/8'')
|
H21(1 1/8'')
|
| CB52 - 28HX
|
5 |
E26(1'') |
E26(1'') |
H51(1 1/8'') |
H21(1 1/8'')
|
| CB52 - 40HX
|
7.5 |
E26(1'') |
E26(1'') |
H51( 5/8'')
|
H21(1 1/8'')
|
| CB52 - 52HX |
10 |
E26(1'') |
E26(1'') |
H52( 5/8'') |
H21(1 1/8'')
|
| CB52 - 66HX
|
12.5 |
E26(1'') |
E26(1'') |
H52( 5/8'’)
|
H21(1 1/8'')
|
| AC120-44EQ
|
15 |
E27(2'') |
E27(2'') |
H54(1 1/8'')
|
D21(2 1/8'')
|
| AC120-58EQ |
20 |
E27(2'') |
E27(2'') |
H54(1 1/8'')
|
D21(2 1/8'')
|
| AC120-86EQ |
30 |
E27(2'') |
E27(2'') |
H55(1 1/8'')
|
D21(2 1/8'')
|
| AC120-118EQ |
40 |
E27(2'') |
E27(2'') |
H55(1 1/8'')
|
D21(2 1/8'')
|
| AC120-158EQ |
50 |
E27(2'') |
E27(2'') |
H56(1 1/8'')
|
D21(2 1/8'')
|
|
| 오일쿨러(OIL COOLER) :CB 26 - V22(1'') CB52 -
V22(1''), V24(1 1/4''), CB76 - B23(2'') |
| * 응축기(CONDENSER), 증발기(EVAPORTOR) : (S1, S2-PT니플식)
(S3, S4-용접식) |
| * 오일쿨러(OIL COOLER) : (S1, S2, S3, S4-평니플식)
|
| * 사용압력(Working Pressure) : 0~30kg/cm2 |
| * 사용온도(Working temperature) : -160'c~+150'c
|
| * 판두께(Plate thick) : 0.4mm |
| * 용접재료(Brazing material) : Cu |
| * 전열면적(Plate trans area) : CB26(0.02m2/p),
CB52(0.051m2/p), AC120(0.095m2/P) |
|
|
|
| |
| 모델 |
마력
|
용량(kcal/h)
|
디멘젼(mm)
|
유량(m3/h)
|
무게(kg)
|
| |
|
|
B |
A |
C |
|
|
| CB14-20H |
1 |
3,600 |
77 |
60 |
207 |
0.96 |
3.28 |
| CB26 - 24H |
2 |
7.200 |
112
|
68
|
311
|
1.44 |
4.32 |
| CB26 - 36H
|
3 |
10.800 |
112 |
96
|
311
|
2.16 |
5.88 |
| CB52 - 28HX
|
5 |
18.000 |
112
|
77.2
|
526
|
3.6 |
8.24 |
| CB52 - 40HX |
7.5 |
27.000 |
112
|
106 |
526 |
5.4 |
11 |
| CB52 - 52HX
|
10 |
36.000 |
112
|
134.8
|
526
|
7.2 |
13.76 |
| CB52 - 66HX
|
12.5 |
45.000 |
112 |
168.4
|
526
|
9.0 |
16.98 |
| AC120-44EQ |
15 |
54.000 |
192
|
117.1
|
617 |
10.8 |
26.96 |
| AC120-58EQ
|
20 |
72.000 |
192
|
150.7 |
617
|
14.4 |
33.12 |
| AC120-86EQ
|
30 |
108.000 |
192
|
217.9
|
617
|
21.6 |
45.44 |
| AC120-118EQ
|
40 |
144.000 |
192
|
294.7
|
617
|
28.8 |
59.52 |
| AC120-158EQ
|
50 |
180.000 |
192
|
390.7
|
617 |
36.0 |
77.12 |
|
| * 적용온도(Temperature) : 응축온도(CT)+2'c 냉각수입출구온도(Water
temp) 32'c/37'c |
| * 압력손실(Pressure Drop) : 0.3kg/cm2 |
|
| |
|
| |
| 모델 |
마력 |
용량(kcal/h)
|
디멘젼(mm)
|
유량(m3/h)
|
무게(kg) |
| |
|
|
B |
A |
C |
|
|
| CB14-20H |
1 |
3,600 |
77 |
60 |
207 |
0.8 |
3.28 |
| CB26 - 24H |
2 |
6.000 |
112 |
68
|
311
|
1.2 |
4.32 |
| CB26 - 36H
|
3 |
9.000 |
112
|
96
|
311
|
1.8 |
5.88 |
| CB52 - 28HX
|
5 |
15.000 |
112
|
77.2 |
526
|
3.0 |
8.24 |
| CB52 - 40HX |
7.5 |
22.500 |
112
|
106
|
526
|
4.5 |
11 |
| CB52 - 52HX |
10 |
30.000 |
112
|
134.8
|
526
|
6.0 |
13.76 |
| CB52 - 66HX
|
12.5 |
37.500 |
112
|
168.4 |
526
|
7.5 |
16.98 |
| AC120-44EQ
|
15 |
45.000 |
192
|
117.1
|
617
|
9.0 |
26.96 |
| AC120-58EQ
|
20 |
60.000 |
192
|
150.7
|
617
|
12.0 |
33.12 |
| AC120-86EQ
|
30 |
90.000 |
192
|
217.9
|
617
|
18.0 |
45.44 |
| AC120-118EQ
|
40 |
120.000 |
192
|
294.7
|
617
|
24.0 |
59.52 |
| AC120-158EQ
|
50
|
150.000
|
192 |
390.7 |
617 |
30.0
|
77.12
|
|
| * 적용온도(Temperature) : 증발온도(ET)+2'c 냉수입출구온도(Water
temp) 12'c/7'c |
| * 압력손실(Pressure Drop) : 0.3kg/cm2 |
|
| |
|
| |
| 모델 |
오일량(m3/h)
|
용량(kcal/h)
|
디멘젼(mm)
|
유량(m3/h)
|
무게(kg) |
| |
|
|
L |
W |
H |
|
|
| CB26 - 18H
|
1.1 |
4.700 |
112
|
52.2
|
311
|
0.94 |
4.1 |
| CB26 - 24H
|
2 |
8.400 |
112
|
66.6
|
311
|
1.68 |
4.8 |
| CB26 - 36H
|
3.6 |
15.500 |
112
|
95.4
|
311
|
3.1 |
6.2 |
| CB26 - 50H
|
4.8 |
20.400 |
112
|
129
|
311 |
4.08 |
8.6 |
| CB52 - 40L
|
7.0 |
29.800 |
112
|
106
|
526
|
5.96 |
11.7 |
| CB52 - 50L |
9.4 |
40.000 |
112 |
130
|
526 |
8.0 |
13.9 |
| CB52 - 60L
|
11.5 |
48.900 |
112
|
154
|
526
|
9.78 |
16.1 |
| CB76 - 50L |
14.7 |
62.300 |
192
|
151
|
617
|
12.46 |
33 |
| CB76 - 60L
|
18.8 |
80.100 |
192
|
179
|
617
|
16.02 |
37 |
| CB76 - 70L
|
23.0 |
97.900 |
192
|
207
|
617
|
19.58 |
41 |
| CB76
- 110H |
33.5
|
142.400
|
192
|
319
|
617
|
28.48
|
58
|
| CB76
- 120H |
35.6
|
151.300
|
192
|
347
|
617 |
30.26
|
62
|
|
| * 적용온도(Temperature) : 오일입출구온도(Oil temp)+55'c/45'c,
|
| 냉각구입출구온도(Water temp) 32'c/37'c |
| * 압력손실(Pressure Drop) : 0.5kg/cm2 |
|
|
| |
